10VW1600
|
Ball Joint Lower Left |
th:M12x1.5 RHT cp:1/5 cs:Ø15,4 / 0,62 kg |
1K0 407 365 C, 5Q0 407 365 A (6) OEM |
 |
10VW1601
|
Ball Joint Lower Right |
th:M12x1.5 RHT cp:1/5 cs:Ø15,4 / 0,62 kg |
1KD 407 366, 1K0 407 366 E (6) OEM |
 |
10VW1605
|
Ball Joint Lower Right |
th:M12x1.5 RHT cp:1/5 cs:Ø15,2 / 0,64 kg |
35D 407 366, 5QD 407 366 (3) OEM |
 |
10VW1606
|
Ball Joint Lower Left |
th:M12x1.5 RHT cp:1/5 cs:Ø15,2 / 0,64 kg |
5QD 407 365, 3C0 407 365 A (3) OEM |
 |
17AU1200
|
Tie Rod End Right |
c:Ø13,2 th:FM16x1,5 RHT / 0,42 kg |
1K0 423 812 F, 1K0 423 812 J (10) OEM |
 |
17AU1201
|
Tie Rod End Left |
c:Ø13,2 th:FM16x1,5 RHT / 0,42 kg |
3C0 423 811 B, 1K1 423 070 X (9) OEM |
 |
17AU1202
|
Tie Rod End Left |
L: 94 cr: 1:5 c: Ø13.22 tp: M12x1.5 th: FM16x1.5 / 0,45 kg |
1K0 423 811 K, 1K0 423 811 J (8) OEM |
 |
17AU1203
|
Tie Rod End Right |
L: 94 cr: 1:5 c: Ø13.22 tp: M12x1.5 th: FM16x1.5 / 0,45 kg |
1K0 423 812 K, 1K0 423 812 G (7) OEM |
 |
20AU1200
|
Axial Joint |
th:MM16x1,5 RHT L:312mm / 0,72 kg |
1K0 423 810 A, 1K1 423 070 AX (16) OEM |
 |
20VW1210
NEW
|
Axial Joint |
0,74 kg |
5WA 423 810 C |
 |
26VW1600
|
Stabiliser Link |
L:335mm / 0,5 kg |
5Q0 411 315, 1KD 411 315 A (14) OEM |
 |
26VW1700
|
Stabiliser Link Rear |
L:70mm Plastic / 0,16 kg |
5Q0 505 465 C, 5Q0 505 465 A (4) OEM |
 |
29AU1200
IN PREPARATION
|
Tie Rod Right |
|
1K0 423 810 A, 1K0 423 812 A (1) OEM |
 |
29AU1201
IN PREPARATION
|
Tie Rod Left |
|
1K0 423 810 A, 1K0 423 811 A (1) OEM |
 |
29AU1202
IN PREPARATION
|
Tie Rod Left |
|
1K0 423 810 A, 1K0 423 811 J (1) OEM |
 |
29AU1203
IN PREPARATION
|
Tie Rod Right |
|
1K0 423 812 K, 1K0 423 810 A (1) OEM |
 |
30AU1604
IN PREPARATION
|
Track Control Arm Left |
|
81A 407 151 C, 81A 407 151 E (1) OEM |
 |
30AU1605
IN PREPARATION
|
Track Control Arm Right |
|
81A 407 152 C, 81A 407 152 E (1) OEM |
 |
30VW1672
|
Track Control Arm Rear Left |
c: Ø12,25 / 1,58 kg |
5Q0 505 223 D, 5Q0 505 223 (1) OEM |
 |
30VW1673
|
Track Control Arm Rear Right |
c: Ø12,25 / 1,59 kg |
5QM 505 224, 5Q0 505 224 D |
 |
30VW1700
NEW
|
Track Control Arm Rear |
2,22 kg |
5QM 505 311, 5Q0 505 311 C (3) OEM |
 |
30VW1702
IN PREPARATION
|
Track Rod Rear |
|
5Q0 505 323 C, 5Q0 505 323 D (1) OEM |
 |
30VW1704
IN PREPARATION
|
Track Rod Rear |
|
5Q0 501 529 F, 5Q0 501 529 D (2) OEM |
 |
38AU1220
|
Silentblock for TCA |
di:Ø14,2 do:Ø38,7 / 0,13 kg |
1K0 505 203 A, 1K0 505 323 N* (1) OEM |
 |
38AU1222
|
Silentblock for TCA |
di: Ø13.4 / do: Ø64.8 / L: 50 / 0,25 kg |
5Q0 407 183 F, 81A 407 183 |
 |
38AU1230
|
Silentblock for TCA |
di:Ø12.1 do:Ø37.4 L:49.8 / 0,14 kg |
5Q0 505 553 |
 |
38AU1231
|
Silentblock for TCA |
di:Ø12.1 do:Ø44.4 L:59.8 / 0,12 kg |
3Q0 505 311 D*, 3Q0 505 311 E* (5) OEM |
 |
38AU1235
|
Silentblock for TCA |
di:Ø12.25 do:Ø60.2 L:63.8mm / 0,19 kg |
1K0 505 541 B, 5Q0 505 541 A (4) OEM |
 |
38AU1290
NEW
|
Bellow Steering |
|
1K0 423 831 A, 1K0 423 831 B (1) OEM |
 |
38AU3020
|
Silentblock for TCA |
di:Ø12,2 do:Ø39,5 / 0,19 kg |
5Q0 407 182 A, 5Q0 407 182 (4) OEM |
 |
38AU3021
|
Silentblock for TCA |
di:Ø13,2 do:Ø65 / 0,35 kg |
5Q0 407 183 D, 5Q0 407 183 G (7) OEM |
 |
38AU3030
|
Silentblock for TCA |
di:Ø12,2 do:Ø39,5 / 0,19 kg |
1K0 407 182, 1K0 407 182 F (4) OEM |
 |
38SK1605
IN PREPARATION
|
Mounting Axle Body |
|
5Q0 501 541 C, 5Q0 501 541 F |
 |
38VW1230
NEW
|
Silentblock for TCA |
0,11 kg |
5Q0 505 311 D*, 5Q0 505 171 |
 |
45VW1602
NEW
|
Strut Mount |
0 kg |
5Q0 513 353 G, 5Q0 513 353 K (2) OEM |
 |
45VW1608
NEW
|
Strut Mount |
0,69 kg |
5Q0 412 331 E, 5Q0 412 331 F (2) OEM |
 |
45VW1609
NEW
|
Engine Mounting |
|
5Q0 199 855 AB, 5Q0 199 855 AF (1) OEM |
